邦諾產品中心
<
>
技術參數
/ TECHNICAL PARAMETERS| 型號 Model NO. | BN400TR | BN800TR |
| 吸盤數量和直徑 Quantity & Diameter of Cup | 8 pcs (300mm) | 8 pcs (300mm) |
| 吸盤車的水平/垂直承重力 Horisontal/Vertical of Working Load Limit | (水平)Horizontal: 400kgs (垂直)Vertical: 300kgs | (水平)Horizontal: 800kgs (垂直)Vertical: 300kgs |
| 吸盤架可翻轉角度 Rotation Degrees of Head | (水平) Horizontal: 360° (左右) Left & Right: 270° (上下) Up & Down: 180° | (水平) Horizontal: 360° (左右) Left & Right: 270° (上下) Up & Down: 180° |
| 最短/最長臂長長度 Min./Max. Length of Arm | 2450mm/3650mm | 3750mm/5930mm |
| 可提升的最大高度 Max. Lifting Height | 3330mm | 5270mm |
| 超載安全控制系統 Overload Safety System | 有 Have | 有 Have |
| 移動方式 Method of Moving | 機動 Motoried | 機動 Motoried |
| 驅動系統 Driving System | 前輪液壓電機驅動 Front wheels-hydraulic motors | 前輪液壓電機驅動 Front wheels-hydraulic motors |
| 電池 Battery | 12V100Am×2sets | 12V100Am×2sets |
| 設備重量 Weight of Equipment | 1400kgs | 1800kgs |
| 包裝尺寸 Package Size | 2760×840×1840mm | 3500×1000×2000mm |
